VPX电源
备注
| 图片 | 型号 | 功率 | 输入电压范围 | 输出 | 输出路数 | 散热方式 | 尺寸 | 效率 | 资料下载 |
 |
RVA750F-6A5.E2 | 750W | 90-264VAC |
+ 12V/60A + 5V/40A +3.3V/20A + 12V/1A - 12V/1A |
5 |
风冷 |
6U/5HP |
88% | |
 |
FSP030 |
400W |
18-36VDC |
+ 12V/10A + 5V/10A +3.3V/15A |
3 | 风冷 | 6U/1英寸厚度 | 85% |  /filedownload/2968272 |
 |
3RCP0114 | 1500W | 176-264VAC |
+48V/30A +12V/10A |
2 | 风冷 | 6U/10HP | 90% | /filedownload/2968283 |
 |
FSP029 | 500W | 176-264 VAC | +12V/33.3A +5V/10A +3.3V/15A |
3 |
强制风冷
|
6U/1英寸 | 85% | /filedownload/2970885 |
 |
3RCP0103 | 300W | 176-264 VAC | +12V/35.0A +3.3V/7.0A +5V/6.0A |
3 | 传导散热 | 3U/1英寸 | 90% | /filedownload/2970884 |
